Catalog No. : THN3361JA61S
Description: 30A 3P HD N5/12 600V NONFUSE
UPC: 783164115475
When it comes to getting the job done right, you can count on safety switches from ABB.
ABB offers a wide variety of general duty switches for residential and light commercial purposes, while the extensive line of heavy-duty switches is best suited for commercial and industrial applications. For the toughest industrial environments — such as cement foundries, steel mills and processing plants — dust-tight and stainless steel switches are available. We also offer a variety of double throw switches for emergency generators.
No matter the application, we’ve got you covered with a rugged, reliable and easy-to-install Spec-Setter safety switch. 30A 3P HD N5/12 600V NONFUSE
View More
View Less
For more info visit:
tnb.ca.abb.com/en/
Descriptors
|
Category |
Accessories |
|
GO Schedule |
S1 |
Specifications
|
Voltage |
600 AC |
|
Amperage |
30 A |
|
Poles |
3 |
|
Fusing |
No Fuse |
|
Enclosure |
NEMA 5, 12 Drip/Dust-tight |
|
240 Vac, NEC Std, 1-ph |
3.0 hp |
|
240 Vac, NEC Std, 3-ph |
10.0 hp |
|
480 Vac, NEC Std, 1-ph |
7.5 hp |
|
480 Vac, NEC Std, 3-ph |
20.0 hp |
|
600 Vac, NEC Std, 1-ph |
10.0 hp |
|
600 Vac, NEC Std, 3-ph |
30.0 hp |
|
250 Vdc |
5.0 hp |
|
GSA Compliance |
No |
Dimensions
|
Depth |
5.40 in |
