Catalog No. : TY46M-2

Description:  CABLE TIE 50LB 7 RED ID 5X.875 MA

UPC: 786210845517

Identification Cable Tie, Red Polyamide (Nylon 6.6) for Temperatures up to 85 Degrees Celsius (185 F) for Indoor Applications, Length of 184.15mm (7.25 Inches), Width of 4.81mm (0.19 Inches), Thickness of 1.41mm (0.055 Inches), Tensile Strength Rating of 220 Newtons (50 pounds), Marking Pad Size of 12.7mm (0.50 Inches) x 26.99mm (1.062 Inches)
View More View Less
For more info visit:  electrification.us.abb.com

Descriptors

Category

I.D. Ties

Specifications

Material

Nylon/Polyamide 6.6

Color

Red

Lock Mechanism

Stainless Steel Barb

Tensile Strength

50 pounds , 220 newtons

Classifications

Brand Name

Ty-Rap

Standard

UL E49405
UL E49405

Dimensions

Width

0.19 in , 4.81 mm

Length

7.25 in , 184.15 mm

Thickness

0.055 in , 1.4 mm

Compliance and Certifications

RoHS RoHS3 Compliant
REACH REACH 240 Compliant
ETIM EC000046 Cable tie

Band width

4.81 mm

Length belt/tape/tie

184.15 mm

Length belt/tape/tie

7.25 inch

Tie thickness

1.41 mm

Tie thickness

0.055 inch

Min. holding force

220 N

Model

Internal toothing

Band closure

Steel nose

Material

Plastic

Material quality

Polyamide (PA)

Surface protection

Untreated

Halogen free

Y

Colour

Red

Transparent

N

Reflective (fluorescent)

N

Solvable fastener

N

MIL approval

N

UL approval

Y
