Alternate Catalog No. : MARN211AT
Ref. No. : 100993 | Catalog No. : MARN211AT
Description: Aux. Contact block, Front mounting, Screw terminal, 1NO+1NC
EAN: 8425095009936
- Terminal numbering in accordance with EN 50011
- Screw- and push-on terminals protected against accidental contact in accordance with VDE 0106 T.100, VB94
- Degree of protection IP20 in accordance with EN60529
- Combinations of front/side mounted auxiliary contact blocks
- Conform to IEC/EN60947-1, EN/60947-5-1
Descriptors
|
Category |
Series M - Compact contactor series up to 12A |
Specifications
|
Series |
Accessories |
|
Range |
Instantaneous auxiliary contacts blocks (Ith = 10A) |
|
Group |
Front mounting |
|
Terminal |
Screw terminal |
|
Aux Contacts |
1NO+1NC |
|
Number of contacts |
2 |
|
Contacts in acc. With EN50005 |
11 |
|
Package (pcs) |
10 |
Classifications
|
ETIM 5.0 |
EC000041 - Auxiliary contact block |
|
ETIM 6.0 |
EC000041 - Auxiliary contact block |
|
ETIM 7 |
EC000041 - Auxiliary contact block |
Dimensions
|
Weight |
0.025 kg |
