Catalog No. : WE-TY27M-8-C

Description:  CABLE TIE 120LB 13 GRAY NYLON 2-PC

UPC: 786210652504

Cable Tie, Gray Polyamide (Nylon 6.6) for Temperatures up to 85 Degrees Celsius (185 F) for Indoor Applications, UL/EN/CSA62275 Type 2/21S Rated for AH-2 Plenum and as a Flexible Cable and Conduit Support, Length of 457.20mm (18.00 Inches), Width of 6.86mm (0.27 Inches), Thickness of 1.09mm (0.043 Inches), Tensile Strength Rating of 540 Newtons (120 Pounds), Special Packs x50
View More View Less
For more info visit:  tnb.ca.abb.com/en/

Descriptors

Category

Cable ties

Specifications

Material

Nylon/Polyamide 6.6

Color

Gray

Lock Mechanism

Stainless Steel Barb

Tensile Strength

120 pounds , 540 newtons

Classifications

Brand Name

Ty-Rap

Dimensions

Width

0.27 in , 7 mm

Length

13.4 in , 340 mm

Thickness

0.06 in , 1.65 mm

Compliance and Certifications

RoHS RoHS3 Compliant
REACH REACH 240 Compliant
TSCA TSCA Section 6(h) Compliant
ETIM EC000046 Cable tie

Length belt/tape/tie

330.2 mm

Length belt/tape/tie

13 inch

Min. holding force

530 N

Model

Internal toothing

Band closure

Steel nose

Material

Plastic

Material quality

Polyamide (PA)

Surface protection

Untreated

Halogen free

Y

Colour

Grey

Transparent

N

Reflective (fluorescent)

N

Text strip

None

Solvable fastener

N

MIL approval

N
