n° de catalogue : STX100-468

Description:  AL JKTD XP FTG HUB 1IN 1.025-1.205

UPC: 786210904719

Made or assembled in Canada. Working with engineers from the Canadian petrochemical, oil and gas industries, Thomas & Betts then introduced the STAR TECK XP fitting. With an easy-to-fill, integral sealing chamber and a disconnectable design requiring minimal cable preparation, this fitting became the benchmark for ease of installation in hazardous environments. A line of liquid and putty sealants was also developed at the same time, eliminating the need for the cement sealants used up to this point.

Star Teck hazardous location aluminum jacketed cable fitting. Hub size of 1 inch. Range over jacket from 1.025 - 1.205 inch.
Afficher plus Afficher moins
Pour plus d’informations, visitez:  tnb.ca.abb.com/fr/
  • Made or assembled in Canada.
  • Easy Fill and Assembly Sealing chamber is easier to fill, requires less sealing compound - saves time, material. Flame path is optimally designed to allow for easy insertion into hub. Quick-turn lock unitizes assembly during installation.
  • Exclusive Power Grip Provides grip that's high upon cable armour - not on first convolution - so precise cable preparation is not critical. Non-magnetic stainless steel Power Grip grounding ring assures 360 degree long-term dependable grounding. Also provides phenomenal tensile pull out resistance.
  • Easy to Install in Tight Spaces Low profile gland nut fits tightest spaces. Has grooves for hammer/ screwdriver installation and flats for wrench-gripping. Durable and reusable with funnel entry for easy cable insertion.
  • Secure, Tight Fit Tapered bushing. Cone-shaped to provide secure, tight fit while eliminating cupping of water in vertical installations.

Descripteurs

Catégorie

Raccords électriques

Application

Emplacements dangereux / Antidéflagrant

Spécifications

Matériau

Aluminium

Couleur

Argent et rouge

Classifications

Marque de produit

Star Teck / AMC

Sous-marque de produit

Star Teck

Standard

UL E82038, CSA 23086

Dimensions

Grosseur

1 pouce

Certification/Norme

CLASS File Number Class CCN Certificate Number Library Number
CSA 23086 441805 N/A 1310604_2016-12-07 N/A
UL E82038 N/A CYMX N/A N/A

Durabilité

Environmental product declaration

PMA_EPD_CON_XPCS_2411

End of Life instructions Teck Fittings

PMA_EPD_CON_PIS_PIH_2410

PMA_EPD_FIT_NVNV_MVNV_2506

EPD PMA – Fittings NVNZ

Documents/outils d'aide

Feuille d'instruction

Cliquez ici

Dessin de vente

Cliquez ici

Cliquez ici

Outils d'assistance

Cliquez ici
