Alternate Catalog No. : NLTT 1000

Catalog No. : NLTT1000

Description:  CU NEMA LUG TEE TAP FOR CABLE BUSES

UPC: 783786740161

Copper NEMA Lug Tees Taps for Cable Buses, Main 1000, 1-1/2 inch x 3 inch x 1-1/2 inch. Bolt Holes Spaced on 1-3/4 inch Centers. Includes Hardware - (2) Stainless Steel 1/2-13 x 3 inch Full Thread Bolts, (2) Stainless Steel 1/2 inch Lock Washers and (2) Stainless Steel 1/2 inch Nuts.
View More View Less
For more info visit:  tnb.ca.abb.com/en/
  • NLTT Series for Copper Mains - Choose the Taps that Match Your System.
  • Multiple Options Available to Accommodate All Sizes of Standard NEMA Drilled Compression Lugs.
  • Tin Plated to Resist Corrosion.

Descriptors

Category

Electrical underground bus connector

Specifications

Connection

Threaded

Conductor Range

1000 kcmil

Material

Copper

Classifications

Brand Name

Homac

Documents/Support Tools

Sales Drawing

Click here
