Alternate Catalog No. : LRTR 4 WS

Catalog No. : LRTR4WS

Description:  TRANSF.INSUL.BAR SCREW ON-NO QUICK

UPC: 783786786091

EPDM Rubber Insulated Disconnectable Transformer Connector, 4 Outlets, Watertight cable and screw ports, Wire Size #12 - 350 mcm, Stud Size 5/8 inch, Length 7 inches, Factory assembled for Right Hand Applications, but can be field changed to Left Hand. Aluminum Cable stop. Ball Bottom Screws aid in the break-up of aluminum oxides. S option.
View More View Less
For more info visit:  tnb.ca.abb.com/en/
  • Disconnectable - Easy to Install or Remove and Fully Insulated with EPDM Rubber
  • Dual-Rated to Accept Aluminum or Copper Conductors

Descriptors

Category

Electrical underground bus connector

Special Features

Left Hand or Right Hand Installation Capability. Disconnectable - easy to install or remove and fully insulated with EPDM Rubber. Dual Rated to accept Aluminum or Copper Conductors.

Application

Stud Mount Transformer Connector

Specifications

Connection

Mechanical

Conductor Range

#12 to 350 kcmil

Number Of Conductors

4

Material

Aluminum Connector, EPDM Rubber coating

Insulation

EPDM Rubber Coating

Classifications

Brand Name

Homac

Dimensions

Size

7 inches

Compliance and Certifications

RoHS RoHS3 Compliant
TSCA TSCA Section 6(h) Compliant
