Alternate Catalog No. : L 2000-4 N
Catalog No. : L2000-4N
Description: CU TP 4HOLE NEMA LUG WIRE 2000
UPC: 783786738809
Tin Plated Copper Four-Hole Straight NEMA Lugs. wire size 2000 kcmil Stranded CU. Installing Dies 2.00, 34, 175. Length 8-1/16 inch. Pad 3-1/16 inch wide x 3-3/16 inch long x 29/64 inch thick. (4) 9/16 inch holes on 1-3/4 inch center. Barrel 3-1/8 inch.
View More
View Less
For more info visit:
tnb.ca.abb.com/en/
- Tin Plated for Resistance Against Corrosion
- All Lugs Marked with Conductor Size and Die References for Easy Identification.
Descriptors
|
Category |
Wire connectors |
|
Special Features |
Tin-Plated to resist corrosion. Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop. Marked with a catalog number, conductor sizes and die references. |
|
Application |
General Applications |
Specifications
|
Connection |
Compression |
|
Material |
Copper |
|
Finish |
Tin Plated |
Classifications
|
Brand Name |
Homac |
Dimensions
|
Size |
8-1/16 inch x 3-1/16 inch wide |
|
Wire Size |
2000 kcmil |
Documents/Support Tools
|
Sales Drawing |
