Alternate Catalog No. : FSY 125-42

Catalog No. : FSY125-42

Description:  FS AL 125 2WAY Y(4-2) 12-500 1-HOLE

UPC: 783786077366

Aluminum Flood-Seal 125 Series Connectors, Service Entrance Connectors, Black PVC Insulated, two-way configuration, 6 Outlets with 1-Hole Each, 4 on one side and 2 on the other. Welded in center between sections, includes 6 Screws. 6.875 inch x 6.444 inch tall. #12 to 500 kcmil.
View More View Less
For more info visit:  tnb.ca.abb.com/en/
  • Designed for Maximum Contact to Ensure Cooler Operation and more Reliable Joints.
  • Outlets Equipped with 1/2 inch Hex-Head Bolts with Captive Belleville Washers to Accept Standard One- or Two-Hole NEMA Aluminum or Copper Lugs.
  • All Outlets Approved for Full Cable Rating - Safe and Reliable.
  • All Connectors are 100 Percent Hi-Pot Tested at 4000V for 60 Seconds.
  • All Flood-Seal Connectors Meer of Exceed ANSI C119.4.
  • RUS Accepted.

Descriptors

Category

Electrical underground bus connector

Special Features

All Outlets Approved for Full cable rating - Safe and Reliable. All Connectors are 100 percent Hi-Pot Tested at 4000 Volts for 60 seconds. Designed for Maximum Contact to ensure Cooler Operation and more reliable joints. Outlets equipped with 1/2 inch Hex-head bolts with Captive Belleville washers to accept Standard one or two hole NEMA Aluminum or Copper Lugs.

Application

Multi-port Connector

Specifications

Connection

Mechanical

Conductor Range

#12 to 500 kcmil

Number Of Conductors

6

Material

Aluminum Connector, PVC Insulation

Color

Black

Insulation

PVC Coating

Number Of Poles

6

Classifications

Brand Name

Homac

Standard

ANSI C119.4
ANSI C119.4

Dimensions

Size

6.875 inch x 6.444 inch
