Description: 1-1/4 TO 3/4IN FEMALE REDUCER IRON

UPC: 786210012636

1-1/4 Inch to 3/4 Inch Female Reducer, Malleable Iron for Use with Rigid/IMC Conduit

View More View Less

For more info visit: tnb.ca.abb.com/en/

Adapt any outlet to the next smaller size of conduit. Hex shoulder makes wrench tightening convienient.
Suitable for use in hazardous locations where general purpose equipment is specifically permitted by the NEC; Class I, Div. 2; Class II, Div. 1 & 2, NEC 501-4(b); 502-4(a)(b); 503-3(a)(b)

Category	Electrical conduit coupling
Application	Female Reducer to Connect Two Different Sizes of Rigid/IMC Conduit

Material

Malleable Iron

Brand Name	T&B Rigid Fittings
Standard	UL E23018, CSA

Trade Size	1-1/4 to 3/4 in
Outside Diameter	1-13/16 in

RoHS	RoHS3 Compliant
TSCA	TSCA Section 6(h) Compliant

ETIM Classification

ETIM EC000938 Enlargement/reducing ring

Thread type inner thread	NPT
Thread size inner thread (inch)	3/4 inch
Thread type outer thread	NPT
Thread size outer thread (inch)	1 1/4 inch
Material	Other
Nickel-plated	N

Sales Drawing
